HONDA JAZZ

Tipe Mesin	1.5 L SOHC 4 silinder segaris, 16 katup i-VTEC + DBW
Kapasitas	1497 cc
Diameter x Langkah	73mm x 86,5mm
Daya Maksimum	120 PS / 6.600 rpm
Torsi Maksimum	45Nm /4.800 rpm
Sistem Bahan Bakar	Electronic Fuel Injection (PGM-FI)
Sistem Transmisi	5 Speed Manual / CVT

Dimensi	3.955mm x 1.694mm x 1.524mm (Standar) 4.035mm x 1.694mm x 1.524mm (RS)
Jarak Pijak Depan	1.492mm (Standar) 1.476mm (RS)
Jarak Pijak Belakang	1.481mm (Standar) 1.466mm (RS)
Jarak Sumbu Roda	2.530mm

Sistem Kemudi	MacPherson Strut
Suspensi Depan	H-Shape Torsion Beam
Suspensi Belakang	5 Link Lateral Rod with Coil Spring and Stabilizer
Rem Depan	Disc
Rem Belakang	Tromol
Sistem Pengereman	ABS + EBD
Sistem Keselamatan	Dual Front SRS Airbags Rangka G-CON + ACE™ Side Impact Beam Pedestrian Protection Pretensioner w/ Load Limiter Seatbelt ISOFIX & Tether
Sistem Keamanan	Smart Key (RS) Keyless Entry Immobilizer Alarm System Smart Entry
Ukuran Ban	175 / 65 R15 (Standar) 185/ 55 R16 (RS)
